ASUS ROG GV601RW-XS96 RAM upgrade specifications

ASUS ROG Flow X16 model GV601RW-XS96 features DDR5-SDRAM memory upgrade specifications with two SO-DIMM slots supporting maximum capacity of 64 GB RAM. Compatible memory operates at 4800 MHz frequency. Upgrade configurations utilize SO-DIMM form factor modules, enabling memory expansion for enhanced system performance and multitasking capabilities on the gaming laptop platform.

Additional Notes

• The ASUS ROG GV601RW-XS96 uses SO-DIMM slots, which are physically smaller than standard DIMM modules and are specific to portable form factors. Replacement or additional memory modules must match this exact form factor; standard desktop DDR5 modules will not physically fit.
• DDR5-4800 MHz operation requires memory modules explicitly rated for 4800 MHz or higher. Installing lower-rated DDR5 modules (such as 4400 MHz variants) will force the system to downclock the memory to the lowest common denominator, resulting in degraded bandwidth and potential performance loss compared to specifications.
• With 2 SO-DIMM slots and a 64 GB maximum capacity, each slot supports up to 32 GB modules. Upgrading to 64 GB total requires purchasing 2x32 GB matched pairs rather than single modules, as mismatched densities between slots can create stability and performance inconsistencies.
• DDR5 memory operates at higher voltages than previous DDR4 generation. Mixed-generation memory installations are not supported; all modules in the 2-slot configuration must be DDR5 exclusively to prevent hardware conflicts or system failure.
• The 64 GB ceiling represents a hard limit imposed by the platform's memory controller architecture. Modules rated beyond 64 GB total capacity will not be recognized by the BIOS and cannot expand the system's usable RAM beyond this threshold.
