ASUS ROG GV601RW-M5093W RAM upgrade specifications
The ASUS ROG Flow X16 GV601RW-M5093W laptop features DDR5-SDRAM memory upgrades with two SO-DIMM slots supporting maximum capacity of 64 GB. Compatible RAM operates at 4800 MHz frequency using the SO-DIMM form factor. Specifications indicate support for DDR5 memory modules, enabling users to expand or upgrade the system memory through the available SO-DIMM slots to reach the maximum 64 GB configuration.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 20 July 2022 |
Additional Notes
- The presence of 2 SO-DIMM slots confirms that the ASUS ROG GV601RW-M5093W utilizes a non-soldered memory architecture, allowing for the total replacement of factory modules rather than relying on a fixed base capacity.
- Operating at a native 4800 MHz frequency on the DDR5 platform ensures high peak bandwidth for multi-threaded workloads, though latency timings will be higher compared to legacy DDR4 standards.
- The 64 GB maximum capacity necessitates the use of 2 matching 32 GB high-density modules to maintain dual-channel symmetric bandwidth and prevent memory controller throttling.
- Upgrading requires specialized tools to navigate the internal chassis layout without disturbing the liquid metal thermal interface often found in this hardware family.
- Installing modules with XMP or overclocking profiles may result in the system defaulting to standard JEDEC speeds if the BIOS does not support manual voltage adjustments.
- Physical clearance within the SO-DIMM housing restricts upgrades to standard height modules, making oversized heat spreaders incompatible with the thin chassis design.
