ASUS ROG GV601RW-M5087W RAM upgrade specifications
The ASUS ROG Flow X16 GV601RW-M5087W features DDR5-SDRAM memory configuration with 2x SO-DIMM slots supporting maximum capacity of 64 GB RAM upgrade. The laptop specifications include DDR5-SDRAM memory operating at 4800 MHz frequency. Compatible memory upgrades utilize SO-DIMM form factor modules, enabling users to expand the system memory from factory-installed capacity up to the maximum 64 GB specification. The dual SO-DIMM slots allow flexible memory upgrade options while maintaining compatibility with the ROG Flow X16 series platform standards.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
Additional Notes
- DDR5 memory operates at reduced latency compared to DDR4 equivalents, but bandwidth constraints emerge when pairing with PCIe 4.0 storage; sustained data transfers between storage and RAM may not saturate the memory bus, limiting practical performance gains in sequential workloads.
- The 2-slot SO-DIMM configuration in the ASUS ROG GV601RW-M5087W creates a single-upgrade ceiling; adding capacity beyond 32 GB per module requires full replacement of both existing sticks rather than incremental expansion, resulting in discarded memory modules.
- 4800 MHz rated speed depends on BIOS configuration and may require manual enabling; systems shipped with conservative profiles operate at lower effective frequencies, meaning actual performance falls short of specification until tuned.
- SO-DIMM form factor restricts module selection to laptop-specific inventory; desktop DDR5 modules remain physically incompatible, narrowing supplier options and potentially increasing per-gigabyte costs relative to standard DIMM upgrades.
- Thermal constraints on mobile platforms reduce sustained memory voltage stability; upgrading to 64 GB full capacity generates measurable heat dissipation in a confined chassis, potentially affecting throttling behavior during intensive multithreaded tasks.
- Warranty-safe upgrades require purchasing DDR5-4800 SO-DIMM modules rated for mobile processors; mixing untested third-party modules with original equipment voids coverage despite DDR5 standardization, necessitating OEM-approved part validation before installation.
