ASUS ROG G513IC-HN004T RAM upgrade specifications
The ASUS ROG Strix G15 G513IC-HN004T features dual SO-DIMM slots supporting DDR4-SDRAM memory upgrades. Maximum RAM capacity reaches 32 GB with compatible modules operating at 3200 MHz frequency. The laptop includes two memory slots for expansion, allowing users to upgrade memory specifications by installing compatible DDR4 SO-DIMM modules to achieve the maximum supported capacity of 32 GB total system RAM.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 22 May 2021 |
Additional Notes
- The ASUS ROG G513IC-HN004T contains 2 SO-DIMM slots, permitting a maximum theoretical capacity of 32 GB when both slots are populated with 16 GB modules.
- DDR4-3200 MHz memory operates within the standard performance envelope for this generation hardware; aftermarket modules rated above 3200 MHz will downclock to the native 3200 MHz specification and provide no practical performance gain.
- SO-DIMM form factor is exclusive to laptop installations; desktop DDR4 UDIMM modules are physically incompatible and cannot be installed regardless of frequency matching.
- Dual-channel memory architecture becomes active only when both slots are occupied; single-module configurations operate in single-channel mode, reducing memory bandwidth availability by approximately 50 percent and creating a performance bottleneck in bandwidth-sensitive workloads.
- Upgrading to maximum capacity requires replacing existing modules rather than adding additional sticks, as no third or fourth slot exists for expansion beyond the 2-slot limitation.
- DDR4-3200 SO-DIMM modules from reputable manufacturers carry minimal compatibility risk; however, sourcing identical replacement modules to the factory-installed pair is advisable to maintain matched timing specifications and warranty eligibility if service becomes necessary.
- Memory upgrades performed by end-users on this platform typically fall outside manufacturer warranty coverage for memory-related claims, though general device warranty remains valid if hardware installation does not cause physical damage to the motherboard or adjacent components.
