ASUS ROG G513IC-HN037W RAM upgrade specifications
ASUS ROG Strix G15 model G513IC-HN037W features dual SO-DIMM memory slots supporting DDR4-SDRAM upgrades. Maximum RAM capacity reaches 32 GB total, with compatible modules operating at 3200 MHz frequency. Upgrade specifications indicate two slots available for memory expansion, allowing users to configure memory according to requirements. DDR4-SDRAM modules in SO-DIMM form factor are required for compatibility with this gaming laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 28 January 2022 |
Additional Notes
- Dual channel memory architecture is only achievable when both slots are occupied with matched modules to maximize transfer rates for the CPU.
- The 32 GB limit restricts the use of 32 GB high density sticks as the motherboard firmware will not address capacities beyond 16 GB per slot.
- Installation of memory with a frequency higher than 3200 MHz will result in automatic downclocking to the system bus limit.
- The ASUS ROG G513IC-HN037W utilizes a laptop specific small outline interface which is physically incompatible with desktop DIMM modules.
- Accessing the internal slots for an upgrade requires the removal of the bottom chassis panel which may involve delicate ribbon cables for integrated lighting components.
- Mixing modules with different latency timings will force the system to operate at the slower common denominator causing a reduction in overall responsiveness.
- Upgrading to the maximum capacity provides the necessary overhead for heavy multitasking and professional video editing workflows that exceed standard gaming requirements.
