ASUS ROG G513IE-R74AT5CB1 RAM upgrade specifications
The ASUS ROG Strix G15 G513IE-R74AT5CB1 features DDR4-SDRAM memory upgrade capability with two SO-DIMM slots supporting maximum capacity of 32 GB total. Compatible memory modules operate at 3200 MHz frequency. Specifications indicate SO-DIMM form factor compatibility for RAM upgrades. The laptop model supports dual-slot memory configuration enabling expandable storage capacity within maximum specifications of 32 GB RAM.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 19 May 2022 |
Additional Notes
- The ASUS ROG G513IE-R74AT5CB1 uses laptop-class SO-DIMM slots, which means replacement modules must be sourced from the mobile memory market rather than desktop DDR4 inventory, affecting part availability and pricing relative to standard DIMM upgrades.
- With 2 slots and a 32 GB maximum capacity ceiling, the system supports a theoretical upgrade from base configuration to 16 GB per module, but this pathway is constrained by the number of installation positions and cannot accommodate larger single-module densities even if they become available.
- The 3200 MHz rated frequency establishes a compatibility boundary; modules rated at higher speeds will function but operate at 3200 MHz, creating no performance benefit for premium-priced faster memory, while modules below 3200 MHz may negotiate to lower frequencies through SPD downgradingdepending on BIOS behavior.
- Dual-channel architecture with 2 SO-DIMM slots means asymmetrical configurations (unequal module capacities or speeds) result in the system running both channels at the lower specification, reducing effective bandwidth and latency characteristics compared to matched pairs.
- SO-DIMM form factor requires low-profile clearance in the chassis; certain memory modules with tall heat spreaders or integrated RGB elements may physically contact internal components or heatsinks, necessitating verification of module height tolerances before installation.
- Warranty preservation during memory upgrades typically allows end-user RAM replacement without voiding coverage on the ASUS ROG G513IE-R74AT5CB1, but module defects or improper installation damage falls outside manufacturer liability, placing responsibility for compatibility verification on the end user.
