ASUS ROG G513QM-HF070T RAM upgrade specifications

ASUS G513QM-HF070T ASUS G513QM-HF070T ASUS G513QM-HF070T ASUS G513QM-HF070T ASUS G513QM-HF070T

ASUS ROG Strix G15 G513QM-HF070T RAM upgrade specifications include DDR4-SDRAM memory with two SO-DIMM slots supporting maximum capacity of 32 GB. Compatible memory modules operate at 3200 MHz frequency. Upgrade slots accommodate standard SO-DIMM form factor modules. Specifications enable memory expansion from factory configuration to maximum supported capacity through compatible DDR4 upgrades.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency3200 MHz
Maximum RAM32 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-3200 (PC4-25600)
Bandwidth25.6 GB/s
Laptop Release date17 September 2021

Additional Notes

  • The dual channel configuration requirement necessitates installing identical modules to maintain peak memory bandwidth for the Ryzen processor within the ASUS G513QM-HF070T.
  • The 32 GB ceiling indicates a firmware limitation despite the processor architecture potentially supporting larger capacities.
  • The 3200 MHz frequency target requires modules with a native JEDEC profile to reach rated speeds because the motherboard lacks XMP or DOCP BIOS adjustments.
  • Physical installation is limited to 260 pin modules due to the SO-DIMM form factor which prevents the use of desktop sized components.
  • Upgrading to the maximum capacity involves replacing both pre installed modules since no vacant expansion slots exist.
  • Latencies remain restricted to standard CL22 timings to ensure stable handshake protocols with the integrated memory controller.
  • Accessing the slots involves removing the base panel which requires care to avoid damaging the internal ribbon cables connected to the light bar system.
