ASUS ROG G513QR-HF119 RAM upgrade specifications
ASUS ROG Strix G15 G513QR-HF119 laptop supports DDR4-SDRAM memory upgrades with maximum capacity of 32 GB. The device features 2x SO-DIMM slots for memory expansion. Compatible RAM modules operate at 3200 MHz frequency. Specifications indicate SO-DIMM form factor for memory components. Upgrade configurations allow users to install additional memory modules up to the maximum supported capacity of 32 GB total RAM across both available slots.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 26 January 2021 |
Additional Notes
- Dual channel memory architecture requires installing identical capacity modules across both slots to maximize memory controller bandwidth.
- The maximum supported capacity of 32 GB imposes a ceiling of 16 GB per slot for the ASUS ROG G513QR-HF119 motherboard.
- Utilizing modules with higher frequencies than 3200 MHz will result in a downclocking bottleneck to the system bus limit.
- Mixing modules with different CAS latencies will force the system to operate at the timings of the slowest installed stick.
- Physical access to the internal SO-DIMM slots typically requires removal of the bottom chassis panel and a careful disconnection of the internal battery to prevent short circuits.
- Standard 1.2V DDR4 SODIMM modules are necessary to ensure compatibility with the power delivery system of the laptop.
- High density 1Rx16 modules may result in lower performance compared to 1Rx8 or 2Rx8 kits due to limited memory bank availability.
