ASUS ROG G513RM-HF150W RAM upgrade specifications

ASUS G513RM-HF150W ASUS G513RM-HF150W ASUS G513RM-HF150W ASUS G513RM-HF150W ASUS G513RM-HF150W

The ASUS ROG Strix G15 G513RM-HF150W laptop features DDR5-SDRAM memory with two SO-DIMM slots for upgrade capability. The upgrade specifications support a maximum RAM capacity of 32 GB total, with compatible modules operating at 4800 MHz frequency. The SO-DIMM form factor enables memory expansion to enhance system performance. Current memory configuration and upgrade options comply with the G513RM-HF150W specifications for optimal compatibility and operation.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR5-SDRAM
Frequency4800 MHz
Maximum RAM32 GB
Voltage1.1V
Number of pins262-pin
InterfacePC5
PC Speed RatingPC5-4800 (PC5-38400)
Bandwidth38.4 GB/s
Laptop Release date20 January 2022

Additional Notes

  • The ASUS ROG G513RM-HF150W supports DDR5 memory at 4800 MHz, which exceeds JEDEC standard DDR5 specifications and requires manufacturer-validated modules to guarantee stability and warranty coverage during upgrades.
  • With 2 SO-DIMM slots and a 32 GB ceiling, symmetric dual-channel configurations deliver maximum bandwidth; asymmetric pairing (mismatched capacities) may reduce performance compared to matched module installations.
  • SO-DIMM form factor constrains physical space; larger heatspreaders present on some DDR5 modules may contact internal chassis components or cooling solutions, requiring verification of module dimensions before purchase.
  • The 32 GB maximum capacity represents a hard limitation set by BIOS firmware; individual modules exceeding 16 GB per slot or non-DDR5 memory types will not be recognized or supported by the system architecture.
  • DDR5-4800 modules are available at multiple JEDEC and XMP specification levels; only DDR5-4800 or slower variants guarantee POST without requiring manual BIOS timing adjustments, as faster profiles may not be validated for this platform.
  • Removal and replacement of SO-DIMM modules bypasses soldered components; this procedure is classified as user-serviceable and does not void hardware warranties when performed according to manufacturer guidelines.
