ASUS ROG G513RM-HF161W RAM upgrade specifications

ASUS G513RM-HF161W ASUS G513RM-HF161W ASUS G513RM-HF161W ASUS G513RM-HF161W ASUS G513RM-HF161W

The ASUS ROG Strix G15 G513RM-HF161W laptop features DDR5-SDRAM memory with upgrade capabilities through two SO-DIMM slots. The specifications support a maximum RAM capacity of 32 GB total, with compatible modules operating at 4800 MHz frequency. The SO-DIMM form factor enables straightforward memory upgrades on the G513RM-HF161W model within the specified slot and capacity constraints.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR5-SDRAM
Frequency4800 MHz
Maximum RAM32 GB
Voltage1.1V
Number of pins262-pin
InterfacePC5
PC Speed RatingPC5-4800 (PC5-38400)
Bandwidth38.4 GB/s
Laptop Release date25 March 2022

Additional Notes

  • Dual channel performance optimization requires the installation of 2 matched memory modules to maximize the bandwidth of the Ryzen architecture.
  • The 32 GB threshold represents the firmware limitation for total addressable space across both SO-DIMM slots.
  • Upgrading the ASUS ROG G513RM-HF161W necessitates the use of 1.1V DDR5 modules to maintain compatibility with the onboard power management integrated circuit.
  • Memory modules exceeding the 4800 MHz frequency will downclock to the maximum supported speed of the internal memory controller.
  • Internal access for component replacement involves removing the bottom chassis panel which utilizes captive screws and ribbon cables for the integrated lighting strip.
  • Physical clearance within the compact chassis restricts the use of memory modules equipped with thick aftermarket heat spreaders.
  • Non-ECC unbuffered memory is the required standard for maintaining system stability during high-load computational tasks.
