ASUS ROG G513RM-HQ166W RAM upgrade specifications
The ASUS ROG Strix G15 series G513RM-HQ166W laptop supports DDR5-SDRAM memory upgrades with specifications including two SO-DIMM slots and maximum RAM capacity of 32 GB. Compatible memory modules operate at 4800 MHz frequency. The upgrade slots accommodate SO-DIMM form factor memory, enabling users to expand the device's RAM capacity for enhanced performance. Memory specifications support the latest DDR5 standard technology for this gaming-class notebook model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 20 January 2022 |
Additional Notes
- Dual channel mode requires identical module pairs to optimize memory bandwidth and reduce latency during intensive processing tasks.
- The absence of soldered memory on the ASUS ROG G513RM-HQ166W motherboard allows for high serviceability and full replacement of factory modules.
- Physical installation is limited to 262 pin hardware interfaces as older 260 pin architecture is electrically and mechanically incompatible.
- Mixing modules with different timings will force the system to default to the slowest common latency profile to maintain stability.
- Capacity expansions beyond the defined limit risk system failure to post or unstable operating system behavior due to BIOS level addressable memory restrictions.
- Integrated graphics performance scales directly with memory speed and will be throttled if mismatched modules downclock the bus.
- Thermal management considerations are necessary when adding high performance modules as denser memory chips generate additional heat within the chassis.
