ASUS ROG G614JU-N3194 RAM upgrade specifications
The ASUS ROG Strix G16 G614JU-N3194 laptop features DDR5-SDRAM memory upgrade specifications with two SO-DIMM slots supporting a maximum capacity of 32 GB total. The memory operates at 4800 MHz frequency. Compatible RAM upgrades utilize the SO-DIMM form factor, enabling users to expand the system's memory capacity from its factory configuration. Specifications indicate support for dual-channel memory architecture through the available slots, allowing for enhanced multitasking and performance optimization in the gaming-focused ROG Strix G16 platform.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 01 March 2023 |
Additional Notes
- The ASUS ROG G614JU-N3194 supports DDR5 memory at 4800 MHz, which operates at significantly higher bandwidth than DDR4 alternatives. This enables faster data transfer to the processor but requires exact DDR5 module compatibility; DDR4 modules cannot be physically or electrically installed in DDR5 slots.
- With 2 SO-DIMM slots and a 32 GB maximum capacity, the system allows for symmetric dual-channel configurations up to 16 GB per module. Asymmetric configurations (for example, 8 GB plus 16 GB) function but operate the smaller module in single-channel mode, creating a performance asymmetry that may impact memory-intensive applications.
- SO-DIMM form factor indicates a compact mobile device with permanent solder connections to the motherboard in many modern laptops. Verification that both memory slots are user-accessible is necessary before purchasing replacement modules, as some laptop designs solder one slot and leave only one user-upgradeable position.
- The 4800 MHz specification represents the standard JEDEC frequency for DDR5. Modules rated above this frequency (5600 MHz, 6400 MHz) may be mechanetically compatible but will downclock to 4800 MHz unless the firmware explicitly supports higher speeds. Confirmation of BIOS support is required to avoid purchasing incompatible high-frequency modules.
- Upgrading from the factory configuration to the 32 GB maximum requires two 16 GB DDR5-4800 SO-DIMM modules. This path preserves warranty validity only if performed by the user without physical damage; any solder joint or connector damage voids coverage.
