ASUS ROG G614JV-N3159 RAM upgrade specifications
ASUS ROG Strix G16 G614JV-N3159 laptop features DDR5-SDRAM memory upgrade specifications. Equipped with 2x SO-DIMM slots supporting maximum RAM capacity of 32 GB. Compatible memory operates at 4800 MHz frequency. SO-DIMM form factor specifications enable RAM upgrades for enhanced system performance. Specifications indicate DDR5 technology compatibility for this gaming laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 01 March 2023 |
Additional Notes
- The ASUS ROG G614JV-N3159 contains 2 SO-DIMM slots operating as a dual-channel configuration, meaning RAM upgrades must be installed in pairs to achieve rated bandwidth performance; installing a single module will operate the system in single-channel mode and reduce memory throughput by approximately 50 percent.
- DDR5-4800 modules are specified for this platform, but DDR5 memory operates with jedec standard compatibility; Intel 13th and 14th generation mobile processors support DDR5-5600 in some configurations, so purchasing faster DDR5 modules will function but will clock down to 4800 MHz, wasting the premium paid for higher-speed variants.
- The 32 GB maximum capacity ceiling means upgrading both SO-DIMM slots to 16 GB modules represents the upper limit; applications requiring more than 32 GB of physical RAM cannot be accommodated without external storage solutions or hardware replacement.
- SO-DIMM memory modules are proprietary laptop-form factors not interchangeable with standard DIMM desktop RAM; sourcing compatible modules requires verification of the SO-DIMM 204-pin standard and DDR5 specification to avoid incompatible purchases.
- Warranty considerations apply if the device remains under manufacturer coverage; removing the bottom panel and accessing SO-DIMM slots may trigger service restrictions on some ASUS ROG units, requiring documentation of the upgrade process or purchase of extended protection plans that explicitly cover user-performed memory installation.
- The 4800 MHz specification operates as a hard memory bus frequency ceiling tied to the mobile processor's integrated memory controller; overclocking memory modules beyond this frequency requires BIOS access and voids standard warranties on ASUS gaming laptops.
