ASUS ROG G614PH-RV047-GAMING RAM upgrade specifications
ASUS ROG Strix G16 G614PH-RV047-GAMING gaming laptop features DDR5-SDRAM memory upgrade specifications. Compatible memory utilizes SO-DIMM form factor across 2 slots, supporting maximum RAM capacity of 64 GB total. Memory operates at 5200 MHz frequency. Upgrade slots accommodate DDR5 specifications for enhanced performance on the G614PH-RV047-GAMING model within the Strix G16 series.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 5200 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-5200 (PC5-41600) |
| Bandwidth | 41.6 GB/s |
Additional Notes
- Dual slot architecture facilitates symmetrical memory configurations to activate dual channel bandwidth for improved CPU throughput.
- The 64 capacity limit necessitates removing existing modules since no vacant expansion headers exist for incremental additions.
- Utilizing memory modules with higher frequency ratings will result in automatic downclocking to match the system firmware bus speed.
- Internal component access for memory replacement on the ASUS ROG G614PH-RV047-GAMING requires the detachment of the lower chassis panel and possible disconnection of the battery to prevent electrical shorting.
- Installation of non-ECC unbuffered modules is mandatory as the SODIMM interface does not support registered or buffered server grade hardware.
- Mixing mismatched module capacities or densities across the 2 slots can trigger a shift to asynchronous dual channel mode which reduces overall memory subsystem efficiency.
- Thermal management remains a factor when choosing high performance modules as the tight physical tolerances of the laptop frame limit the use of thick aftermarket heat spreaders.
