ASUS ROG G614PM-DICRV106W RAM upgrade specifications
The ASUS ROG Strix G16 G614PM-DICRV106W laptop features DDR5-SDRAM memory upgrade capabilities. The system includes 2x SO-DIMM slots supporting a maximum RAM capacity of 64 GB. Compatible memory modules operate at 5200 MHz frequency. The SO-DIMM form factor specifications enable RAM upgrade configurations for enhanced multitasking and performance requirements. Memory expansion maintains compatibility with the G614PM-DICRV106W platform specifications.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 5200 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-5200 (PC5-41600) |
| Bandwidth | 41.6 GB/s |
Additional Notes
- The ASUS ROG G614PM-DICRV106W supports DDR5 memory at 5200 MHz, which operates at significantly higher bandwidth than previous DDR4 standards. This frequency requirement restricts compatible modules to DDR5-5200 or faster specifications; slower DDR5 variants will downclock to match system limitations.
- With 2 SO-DIMM slots and a 64 GB maximum capacity ceiling, each slot accommodates a maximum 32 GB module. Single-slot configurations will leave performance on the table due to loss of dual-channel memory bandwidth, reducing effective throughput by approximately 50 percent compared to dual-populated configurations.
- SO-DIMM form factor constraints eliminate compatibility with standard UDIMM desktop modules. Sourcing DDR5 SO-DIMM capacity above 32 GB per module remains supply-limited; availability of matched 32 GB pairs may require extended lead times or purchasing from specialized retailers.
- The 64 GB capacity limit means maximum upgrade yields 64 GB total system memory. Applications exceeding this threshold will rely entirely on storage-based virtual memory, introducing substantial latency penalties. Workloads such as large dataset processing or virtualization environments should verify their memory requirements against this upper bound before purchasing.
- DDR5-5200 SO-DIMM modules typically command price premiums over DDR4 equivalents and lower-frequency DDR5 variants. Warranty provisions for RAM upgrades generally remain intact when using compatible specifications from authorized vendors, though OEM-validated module lists should be consulted prior to purchase.
