ASUS ROG G713QE-HX025T RAM upgrade specifications
The ASUS ROG Strix G17 G713QE-HX025T features DDR4-SDRAM memory upgrade capabilities with 2x SO-DIMM slots. Maximum RAM capacity reaches 32 GB total. Compatible memory operates at 3200 MHz frequency with SO-DIMM form factor. Specifications enable RAM upgrade from stock configurations to full maximum capacity through standard SO-DIMM modules. Memory specifications support high-performance gaming and multitasking requirements for this ROG Strix laptop series.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 13 August 2021 |
Additional Notes
- The ASUS ROG G713QE-HX025T supports a maximum of 32 GB total capacity across 2 SO-DIMM slots, meaning each slot accepts a single 16 GB module at maximum density. Configurations using 2x16 GB modules represent the practical ceiling for this platform.
- DDR4-3200 MHz specification indicates that memory rated above 3200 MHz will operate at 3200 MHz due to Intel's memory controller limitations on the underlying processor generation. Higher-frequency modules (DDR4-3600, DDR4-4000) offer no performance advantage and incur unnecessary cost.
- SO-DIMM form factor confines replacement to laptop-specific memory modules. Desktop DDR4 modules (UDIMM) are mechanially incompatible and cannot be installed regardless of speed or capacity matching.
- The 2-slot architecture means that single-module upgrades leave one slot populated and one empty. Asymmetrical dual-channel configurations (8 GB + 16 GB, for example) will function but forfeit interleaving benefits. Matched pairs of identical capacity and timing specifications optimize memory throughput.
- Upgrading from factory-installed configurations to the 32 GB maximum requires removal of pre-installed modules. Many manufacturers void warranty coverage if internal components are accessed, necessitating verification of service policies before disassembly.
- Memory bandwidth saturation occurs when both slots operate simultaneously. If the factory configuration uses a single 8 GB module, adding a second module increases available bandwidth by approximately 50 percent, though latency remains unchanged.
