ASUS ROG G713QR-K4017T RAM upgrade specifications
ASUS ROG Strix G17 G713QR-K4017T RAM upgrade specifications include two SO-DIMM memory slots supporting DDR4-SDRAM at 3200 MHz frequency. Maximum compatible RAM capacity reaches 32 GB total. Upgrade options accommodate standard SO-DIMM form factor modules. Specifications enable memory expansion to enhance laptop multitasking and performance capabilities through compatible DDR4 RAM upgrades.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 08 January 2023 |
Additional Notes
- The dual slot configuration requires removing both existing modules to reach the maximum capacity since no memory is soldered to the mainboard.
- The ASUS ROG G713QR-K4017T architecture utilizes a dual channel memory controller that scales bandwidth performance only when identical module densities occupy both slots.
- Upgrading beyond the 32 GB threshold lacks official firmware validation and results in system instability or a failure to boot due to BIOS limitations.
- The 3200 MHz frequency is the maximum kit speed the processor can maintain without engaging in overclocking profiles that increase thermal output.
- Physical installation is limited to 260 pin small outline modules as standard desktop DIMM hardware is physically incompatible with the chassis height.
- Latency timings should match the original factory silicon to prevent the motherboard from downclocking all installed memory to the lowest common denominator.
- Replacing internal components requires disabling the battery in the software interface or disconnecting the physical bridge to prevent short circuits on the motherboard surface.
