ASUS ROG G713RM-KH011W-BE RAM upgrade specifications
The ASUS ROG Strix G17 G713RM-KH011W-BE features DDR5-SDRAM memory upgrade specifications with two SO-DIMM slots supporting maximum capacity of 32 GB RAM. Compatible memory modules operate at 4800 MHz frequency. The laptop supports SO-DIMM form factor upgrades, enabling users to expand memory capacity through the available upgrade slots. These specifications define the RAM upgrade compatibility and performance parameters for the G713RM-KH011W-BE model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 10 January 2022 |
Additional Notes
- Dual channel memory architecture requires installing modules in pairs to achieve maximum theoretical memory bandwidth.
- The 32 GB motherboard firmware limitation prevents the use of higher density 24 GB or 32 GB modules in the available slots.
- Installation of memory with timings faster than the 4800 MHz standard will result in downclocking to the default frequency dictated by the chipset.
- The ASUS ROG G713RM-KH011W-BE utilizes a SO-DIMM layout which necessitates the removal of existing modules to reach the maximum capacity if both slots are currently occupied.
- Upgrading memory requires the detachment of the bottom chassis panel and the careful handling of internal battery connectors to prevent electrical shorting during the swap.
- DDR5 technology operates at lower voltages than previous generations, meaning physical pin configurations are incompatible with DDR4 hardware.
- Internal heat management relies on unobstructed airflow over the memory area, so any aftermarket heat spreaders must fit within the slim vertical clearance of the chassis.
