ASUS ROG G713RM-LL061 RAM upgrade specifications
ASUS ROG Strix G17 G713RM-LL061 laptop features two SO-DIMM memory slots supporting DDR5-SDRAM upgrade specifications. Compatible RAM modules operate at 4800 MHz frequency with maximum memory capacity of 32 GB. Upgrade configurations available include single or dual module installations to expand system memory up to specifications limit. SO-DIMM form factor ensures compatibility with gaming notebook requirements.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 17 February 2022 |
Additional Notes
- The ASUS ROG G713RM-LL061 architecture imposes a 32 GB ceiling due to chipset memory controller limitations rather than physical slot restrictions.
- DDR5-4800 represents the JEDEC baseline specification, meaning modules rated at higher frequencies will downclock to 4800 MHz when installed in this system.
- SO-DIMM DDR5 modules require 262-pin connectors and operate at 1.1V, making DDR4 modules physically and electrically incompatible despite similar form factors.
- Dual-channel operation necessitates matched module capacities in both slots to avoid reverting to single-channel mode, which halves memory bandwidth.
- The 4800 MHz specification translates to PC5-38400 in alternative nomenclature, relevant when cross-referencing module compatibility.
- ECC SO-DIMM modules will function without error correction on this consumer platform, operating in non-ECC mode with no performance penalty.
- Installation requires accessing the bottom panel, which typically voids no warranties under consumer protection laws in most jurisdictions, though regional variations apply.
- Mixed-capacity configurations such as 8 GB plus 16 GB will function but prevent flex mode optimization available with identical module pairs.
- The 4800 MT/s transfer rate delivers theoretical bandwidth of 38.4 GB/s per channel, totaling 76.8 GB/s in dual-channel configuration.
- DDR5's on-die ECC operates independently of module type and provides internal error correction even with non-ECC SO-DIMMs.
- Ambient temperatures exceeding 35°C may trigger thermal throttling in densely populated 32 GB configurations during sustained memory-intensive workloads.
- XMP 3.0 profiles embedded in aftermarket modules remain dormant without BIOS support, reverting to JEDEC 4800 MHz defaults.
