ASUS ROG G814JV-N5004W RAM upgrade specifications
ASUS ROG Strix G18 G814JV-N5004W RAM upgrade specifications include DDR5-SDRAM memory with 2x SO-DIMM slots supporting maximum capacity of 32 GB. The laptop features SO-DIMM form factor memory modules operating at 4800 MHz frequency. Compatible DDR5 memory upgrades enable users to expand system RAM for enhanced multitasking and performance capabilities on the G814JV-N5004W gaming laptop.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 24 April 2023 |
Additional Notes
- The ASUS ROG G814JV-N5004W contains 2 SO-DIMM slots with a combined ceiling of 32 GB, necessitating dual 16 GB modules to reach maximum capacity rather than single-module configurations.
- DDR5-4800 MHz operation requires strict module compatibility verification, as older DDR5 inventory rated below 4800 MHz may function at reduced speeds or trigger BIOS compatibility warnings despite physical fit.
- SO-DIMM form factor constraints eliminate standard desktop DDR5 modules entirely; laptop-specific memory is mandatory, and cross-generation DDR5 modules from different manufacturers may exhibit latency negotiation delays during cold boot sequences.
- Upgrading from factory configuration to 32 GB maximum will not create thermal management conflicts, as SO-DIMM density has minimal heat output, but the density increase may affect internal airflow routing if cooling ducts proximity exists.
- BIOS firmware version directly controls DDR5 stability thresholds and frequency recognition; systems with outdated BIOS may not acknowledge 4800 MHz rated modules and instead default to 4400 MHz operation, reducing effective bandwidth by approximately 9 percent.
- Warranty preservation during RAM upgrades typically remains intact on ASUS systems when end-user installation is performed, provided memory modules meet factory-certified DDR5 specifications and no physical damage occurs to surrounding components.
- Single-slot population creates asymmetric memory architecture, forcing the controller into single-channel mode with bandwidth penalties; dual-slot population at any capacity automatically engages dual-channel operation with corresponding latency reduction.
