ASUS ROG G533QS-HF123T RAM upgrade specifications
ASUS ROG Strix SCAR 15 G533QS-HF123T RAM upgrade specifications include DDR4-SDRAM memory compatible with 2x SO-DIMM slots. Maximum supported capacity reaches 64 GB total memory. The laptop utilizes SO-DIMM form factor modules operating at 3200 MHz frequency. Specifications provide details on memory upgrade compatibility and maximum RAM configuration for this gaming laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 08 October 2021 |
Additional Notes
- Dual channel mode requires identical module pairs across both slots to maximize the bandwidth of the AMD Ryzen processor architecture found in the ASUS ROG G533QS-HF123T.
- The system firmware prevents the use of XMP profiles, meaning aftermarket modules must have a JEDEC profile for 3200 MHz to avoid downclocking to 2666 MHz or 2400 MHz.
- Upgrading to the 64 GB maximum requires removing all existing factory modules because no additional unoccupied slots exist.
- Installation of high density 1Rx16 modules may result in significant frame rate drops compared to 1Rx8 or 2Rx8 organized memory banks.
- Physically accessing the SO-DIMM slots requires the removal of the bottom chassis panel and the disconnection of the LED light bar cables to prevent electrical shorts or ribbon damage.
- The integrated memory controller maintains stability at 1.2V, making high voltage overclocking modules incompatible with this motherboard regulation.
- Total addressable memory capacity supports heavy workstation tasks like 4K video editing and virtual machine hosting that exceed typical gaming requirements.
