ASUS ROG G533QS-HF078T RAM upgrade specifications

ASUS G533QS-HF078T ASUS G533QS-HF078T ASUS G533QS-HF078T ASUS G533QS-HF078T ASUS G533QS-HF078T

The ASUS ROG Strix SCAR 15 G533QS-HF078T supports DDR4-SDRAM memory upgrades through two SO-DIMM slots. Maximum RAM capacity reaches 64 GB total, with compatible memory operating at 3200 MHz frequency. The laptop features SO-DIMM form factor slots for memory expansion. Specifications indicate the G533QS-HF078T can accommodate significant memory upgrades to enhance multitasking performance and applications requiring substantial RAM allocation.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency3200 MHz
Maximum RAM64 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-3200 (PC4-25600)
Bandwidth25.6 GB/s
Laptop Release date10 June 2021

Additional Notes

  • Dual channel architecture requires matching pair modules to eliminate memory bus bandwidth bottlenecks during high computational loads.
  • The absence of soldered memory on the ASUS G533QS-HF078T motherboard allows for the total replacement of factory modules to reach maximum capacity.
  • Installation of memory modules exceeding 3200 MHz will result in automatic downclocking to remain within the hardware stability limits of the chipset.
  • Physical clearance within the chassis restricts compatibility to standard height SO-DIMM modules and excludes those with integrated bulky heat spreaders.
  • Upgrading to 64 GB necessitates the removal of all existing pre-installed hardware because no vacant slots are available for expansion.
  • High density 32 GB modules must use a non-ECC unbuffered configuration to ensure successful POST sequences and system stability.
  • Latencies remain restricted by the BIOS profile which typically lacks support for manual XMP timing adjustments found in desktop counterparts.
