ASUS ROG G533QS-HF030T RAM upgrade specifications
The ASUS ROG Strix SCAR 15 G533QS-HF030T supports DDR4-SDRAM memory upgrades through two SO-DIMM slots. Maximum supported capacity reaches 64 GB total, with compatible modules operating at 3200 MHz frequency. The laptop features SO-DIMM form factor specifications, enabling memory upgrades for enhanced multitasking performance. Current upgrade slots accommodate additional DDR4 RAM to achieve maximum capacity specifications.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 19 February 2021 |
Additional Notes
- Dual channel memory architecture requires installing identical capacity modules to achieve peak memory bandwidth and reduce system latency.
- The absence of soldered memory on the ASUS ROG G533QS-HF030T motherboard allows for a full replacement of the pre-installed modules without leaving mismatched components.
- Utilizing 32 rank configurations when upgrading to 64 GB provides higher data throughput compared to single rank modules in memory intensive workloads.
- Operating at 3200 MHz requires modules to support JEDEC standard profiles to ensure stability without manual BIOS adjustments.
- Physical installation is limited to 260 pin SO-DIMM hardware which prevents the use of older DDR3 or newer DDR5 components.
- Upgrading to the maximum supported capacity minimizes page file reliance on the solid state drive thereby extending the lifespan of the storage hardware.
- System stability depends on using non ECC unbuffered memory modules as the chipset does not support error correction protocols.
