ASUS ROG G634JY-93D49PB1 RAM upgrade specifications

ASUS G634JY-93D49PB1 ASUS G634JY-93D49PB1 ASUS G634JY-93D49PB1 ASUS G634JY-93D49PB1 ASUS G634JY-93D49PB1

ASUS ROG Strix SCAR 16 G634JY-93D49PB1 laptop RAM upgrade specifications include DDR5-SDRAM memory with 2x SO-DIMM slots supporting a maximum capacity of 64 GB. The compatible memory operates at 4800 MHz frequency and uses SO-DIMM form factor. Current specifications enable users to upgrade existing memory modules to increase overall system memory capacity for enhanced performance.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR5-SDRAM
Frequency4800 MHz
Maximum RAM64 GB
Voltage1.1V
Number of pins262-pin
InterfacePC5
PC Speed RatingPC5-4800 (PC5-38400)
Bandwidth38.4 GB/s

Additional Notes

  • Dual channel architecture requires matching memory modules in both slots to reach peak theoretical bandwidth and avoid latency penalties.
  • The ASUS ROG G634JY-93D49PB1 utilizes a non-soldered configuration allowing for the total replacement of factory modules during future capacity expansions.
  • Installing high density 32 GB sticks per slot reaches the motherboard trace limit for stable voltage regulation.
  • Mismatching frequency ratings between the two slots forces the memory controller to downclock to the slowest speed present.
  • Physical installation necessitates the use of plastic pry tools to prevent short-circuiting internal components or damaging the chassis clips.
  • Memory modules exceeding the 4800 MHz specification will automatically operate at the system bus limit regardless of XMP or EXPO profiles.
  • Upgrading to the 64 GB maximum requires the removal of existing hardware as no additional vacant slots exist for expansion.
