ASUS ROG G733CX-XS97 RAM upgrade specifications
ASUS ROG Strix SCAR 17 SE model G733CX-XS97 features DDR5-SDRAM memory upgrade specifications. The laptop contains two SO-DIMM slots supporting maximum RAM capacity of 64 GB. Compatible memory operates at 4800 MHz frequency. Specifications indicate SO-DIMM form factor for RAM modules. Upgrade options allow for memory expansion through available slots to reach maximum capacity specifications.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 04 May 2022 |
Additional Notes
- The ASUS ROG G733CX-XS97 operates exclusively on DDR5 technology, eliminating backward compatibility with DDR4 modules due to physical notch positioning and voltage architecture differences.
- The 4800 MHz specification represents JEDEC baseline speed for DDR5, leaving headroom for XMP-enabled modules rated at 5200 MHz or 5600 MHz if the system BIOS supports SPD profile activation.
- Dual SO-DIMM configuration enforces symmetric population for dual-channel operation, meaning mixed capacity configurations will default to single-channel mode or flex mode with performance degradation.
- The 64 GB ceiling requires 2 modules of 32 GB each, restricting future expansion beyond initial installation without replacing existing memory.
- SO-DIMM physical constraints limit heat spreader height to approximately 30mm, preventing installation of desktop-grade UDIMM modules despite shared DDR5 protocol.
- Warranty preservation typically requires non-destructive access through bottom panel removal, as soldered or riveted construction may void coverage if disassembly damages chassis integrity.
- Mixing modules with different CAS latency ratings will force all sticks to operate at the slowest common timing, potentially underutilizing higher-binned memory investments.
- DDR5 on-die ECC operates independently of system-level error correction, providing data integrity without requiring ECC-registered modules unavailable in consumer SO-DIMM format.
- Power delivery shifts from motherboard to individual DIMM power management ICs, making module quality critical for voltage regulation stability under sustained workloads.
