ASUS ROG G733QS-HG001 RAM upgrade specifications
The ASUS ROG Strix SCAR 17 G733QS-HG001 features DDR4-SDRAM memory upgrade specifications with 2x SO-DIMM slots supporting a maximum RAM capacity of 64 GB. The compatible memory operates at 3200 MHz frequency and utilizes the SO-DIMM form factor. Specifications indicate available upgrade slots for enhanced memory configuration on the G733QS-HG001 laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 22 January 2021 |
Additional Notes
- The dual slot architecture requires the removal of existing modules to reach the maximum capacity because there are no additional vacant slots for expansion.
- Utilizing 2 matching modules is necessary to enable dual channel bandwidth which prevents memory related bottlenecks during heavy CPU workloads.
- Installation of high performance memory depends on JEDEC profile compatibility at 1.2V to ensure the rated speed is achieved without BIOS level XMP settings.
- The ASUS ROG G733QS-HG001 chassis requires a precision screwdriver set and a plastic prying tool to release the bottom panel clips without causing static discharge or cosmetic damage.
- Integrated light bar cables are attached to the lower casing which necessitates careful lifting to avoid tearing the ribbon connectors during internal access.
- Selecting modules with low CAS latency reduces system response times and improves frame consistency in memory intensive applications.
- Mixing modules of different capacities or timings will force the system to operate at the specifications of the slowest component which degrades overall efficiency.
