ASUS ROG G733QS-K4016T-BE RAM upgrade specifications

ASUS G733QS-K4016T-BE ASUS G733QS-K4016T-BE ASUS G733QS-K4016T-BE ASUS G733QS-K4016T-BE ASUS G733QS-K4016T-BE

ASUS ROG Strix SCAR 17 G733QS-K4016T-BE laptop features DDR4-SDRAM memory upgrade specifications. Compatible DDR4 modules install in 2x SO-DIMM slots, supporting maximum RAM capacity of 64 GB. Memory operates at 3200 MHz frequency. Upgrade specifications enable replacing or expanding existing memory modules to enhance system performance and multitasking capabilities on gaming and professional workloads.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency3200 MHz
Maximum RAM64 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-3200 (PC4-25600)
Bandwidth25.6 GB/s
Laptop Release date21 January 2021

Additional Notes

  • The dual channel architecture implies that memory must be installed in matching pairs to achieve peak memory bandwidth and avoid performance throttle points during heavy workloads.
  • Upgrading the **ASUS ROG G733QS-K4016T-BE** to the 64 GB threshold requires the replacement of both factory modules since no additional expansion slots exist beyond the primary 2 slots.
  • The choice of DDR4 3200 MHz modules necessitates checking for JEDEC profile compatibility to ensure the system reaches rated speeds without manual BIOS adjustments.
  • Physical installation of new modules requires a non-marring pry tool to safely release the plastic clips of the bottom chassis plate without causing cosmetic damage to the casing.
  • Thermal management remains a factor as high capacity 32 GB modules generate more localized heat compared to lower density sticks during sustained data transfers.
  • System stability at the 64 GB maximum capacity depends on utilizing unbuffered SODIMMs because registered or ECC memory types will result in a failure to boot.
  • Latency timings should match between the 2 slots to prevent the motherboard from defaulting to the slowest common denominator clock speed.
