ASUS ROG G835LR-SA006W RAM upgrade specifications

ASUS G835LR-SA006W ASUS G835LR-SA006W ASUS G835LR-SA006W ASUS G835LR-SA006W

ASUS ROG Strix SCAR 18 G835LR-SA006W supports DDR5-SDRAM memory upgrades via two SO-DIMM slots. Maximum RAM capacity reaches 64 GB total. Memory specifications include 5600 MHz frequency support. Compatible RAM upgrades utilize SO-DIMM form factor modules. Specifications enable users to expand memory capacity up to manufacturer-supported limits for enhanced system performance.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR5-SDRAM
Frequency5600 MHz
Maximum RAM64 GB
Voltage1.1V
Number of pins262-pin
InterfacePC5
PC Speed RatingPC5-5600 (PC5-44800)
Bandwidth44.8 GB/s

Additional Notes

  • The ASUS ROG G835LR-SA006W uses DDR5 SO-DIMM modules, which are physically shorter than standard DIMM form factors and require specific laptop-compatible memory products rather than desktop equivalents.
  • Dual SO-DIMM slots create a symmetric upgrade scenario where both channels operate in parallel, enabling dual-channel bandwidth when both slots are populated; populating only 1 slot reduces memory throughput by approximately 50 percent.
  • The 5600 MHz specification represents the validated frequency for this platform; memory modules marketed at higher speeds may require manual BIOS tuning or may downclock to this rated speed, potentially negating performance gains from overclocked modules.
  • Upgrading from factory configuration to the 64 GB maximum requires high-capacity SO-DIMM modules (32 GB per slot), which command a significant cost premium compared to lower-density options due to limited market penetration of this form factor and capacity combination.
  • DDR5 SO-DIMM modules have tighter compatibility windows than DDR4 predecessors; mixing modules from different manufacturers or production batches risks compatibility issues, voltage instability, or boot failures despite identical speed and capacity specifications.
  • Warranty implications depend on ASUS service policy; opening the base panel to access memory slots may trigger coverage restrictions if the system requires manufacturer installation rather than user-performed upgrades.
  • The 2-slot architecture provides no upgrade flexibility beyond the 64 GB ceiling; no additional memory slots exist for future expansion once both SO-DIMM positions are filled.
