ASUS ROG G533QS-HQ132T RAM upgrade specifications

ASUS G533QS-HQ132T ASUS G533QS-HQ132T ASUS G533QS-HQ132T ASUS G533QS-HQ132T ASUS G533QS-HQ132T

The ASUS ROG Strix G533QS-HQ132T laptop features DDR4-SDRAM memory upgradeable through two SO-DIMM slots. Maximum supported capacity reaches 64 GB total RAM. Compatible memory modules operate at 3200 MHz frequency. Upgrade specifications indicate SO-DIMM form factor compatibility, enabling users to expand system memory beyond factory-installed configurations. Specifications support DDR4 technology for enhanced multitasking and gaming performance on the G533QS-HQ132T model.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency3200 MHz
Maximum RAM64 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-3200 (PC4-25600)
Bandwidth25.6 GB/s
Laptop Release date10 December 2020

Additional Notes

  • Dual channel memory architecture requires installing two identical modules to reach maximum theoretical bandwidth for the AMD Ryzen processor.
  • The absence of soldered memory on the ASUS G533QS-HQ132T motherboard ensures that the entire system memory can be replaced if a single module fails.
  • Upgrading to the maximum supported capacity necessitates the removal of both pre installed modules because no additional expansion slots exist.
  • Integrated graphics performance scales directly with the latency timings of the secondary memory bank.
  • Physical installation requires standard small form factor modules as desktop sized DIMM hardware is incompatible with the chassis height.
  • System stability at 3200 MHz depends on modules supporting JEDEC profiles to avoid downclocking to lower baseline frequencies during initial boot.
  • Utilizing high density 32 GB sticks to reach the 64 GB limit may increase internal thermal output within the specialized cooling zones.
