ASUS ROG G712LW-EV010 RAM upgrade specifications
The ASUS ROG Strix G712LW-EV010 laptop features DDR4-SDRAM memory upgrade specifications with two SO-DIMM slots supporting a maximum RAM capacity of 32 GB. Compatible memory modules operate at 3200 MHz frequency. The upgrade specifications indicate the laptop can accommodate enhanced memory configurations for improved performance and multitasking capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 04 November 2020 |
Additional Notes
- Dual channel mode requires identical module capacities across both slots to ensure maximum memory bandwidth efficiency for the processor.
- The maximum capacity limit indicates that 32 GB modules are incompatible with the motherboard firmware of this ASUS ROG G712LW-EV010.
- System stability depends on using non ECC unbuffered modules as the hardware architecture lacks support for error correcting code memory.
- Physical access to the SO-DIMM slots requires the removal of the bottom chassis cover which involves disconnecting the internal battery to prevent electrical short circuits.
- Installing memory with higher frequencies than 3200 MHz will result in the hardware automatically downclocking the modules to match the maximum supported bus speed.
- The absence of soldered memory on the board allows for the total replacement of factory modules rather than relying on a single expansion point.
- Thermal management constraints in the compact SO-DIMM area suggest avoiding modules with thick aftermarket heat spreaders that may interfere with the chassis closure.
