ASUS ROG GL703GE-GC024 RAM upgrade specifications
The ASUS ROG Strix GL703GE-GC024 gaming laptop features two SO-DIMM memory slots supporting DDR4-SDRAM upgrade capacity. The system accommodates maximum RAM of 32 GB total, with compatible memory operating at 2666 MHz frequency specifications. Upgrade options allow installation of DDR4 SO-DIMM modules to enhance multitasking performance and gaming capabilities on this professional-grade gaming platform.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 25 May 2019 |
Additional Notes
- Dual channel mode requires identical module capacities in both slots of the ASUS ROG GL703GE-GC024 to optimize memory bandwidth and reduce frame time latency.
- The internal hardware architecture limits memory expansion to 16 GB per slot due to the physical density constraints of supported 260 pin modules.
- Installing modules with frequencies exceeding 2666 MHz results in automatic downclocking to the clock speed defined by the system firmware.
- Symmetric memory configurations alleviate potential bottlenecks during CPU intensive tasks and multi threaded rendering processes.
- Accessing the SO-DIMM slots involves removing the base panel which may require specific tools to avoid damaging the integrated plastic clips.
- Mixing modules from different manufacturers or with varying CAS latencies forces the system to operate at the timings of the slowest installed component.
- The maximum supported capacity ensures sufficient headroom for high resolution video editing and complex virtual machine environments without relying on slower disk based paging files.
