ASUS ROG GL704GW-EV003T RAM upgrade specifications

ASUS GL704GW-EV003T ASUS GL704GW-EV003T ASUS GL704GW-EV003T ASUS GL704GW-EV003T ASUS GL704GW-EV003T

ASUS ROG Strix GL704GW-EV003T laptop features two SO-DIMM memory slots supporting DDR4-SDRAM upgrade specifications. Maximum RAM capacity reaches 32 GB total, with compatible modules operating at 2666 MHz frequency. Upgrade slots accommodate standard SO-DIMM form factor memory modules for enhanced performance and multitasking capabilities on this gaming laptop platform.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency2666 MHz
Maximum RAM32 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-2666 (PC4-21328)
Bandwidth21.3 GB/s
Laptop Release date21 February 2019

Additional Notes

  • The dual channel configuration requires identical module pairs to achieve peak memory bandwidth and prevent system downclocking.
  • The ASUS ROG GL704GW-EV003T architecture utilizes a 260 pin physical interface which precludes the use of desktop modules or older generation hardware.
  • Upgrading to the 32 GB threshold necessitates the replacement of both factory modules since no vacant expansion slots exist for supplemental capacity.
  • Installation of memory modules with speeds exceeding 2666 MHz results in automatic downclocking to the chipset latency limit without providing a performance advantage.
  • The internal layout requires the removal of the bottom chassis panel for component access which may involve breaking factory tamper seals depending on regional service policies.
  • High density 16 GB modules must be unbuffered and non ECC to ensure compatibility with the mobile processor architecture.
