ASUS ROG GL753VE-GC166T RAM upgrade specifications
The ASUS ROG Strix GL753VE-GC166T gaming laptop features DDR4-SDRAM memory upgrade capability with two SO-DIMM slots supporting maximum 32 GB total capacity. Compatible memory modules operate at 1600 MHz frequency. Specifications indicate SO-DIMM form factor compatibility for RAM expansion. The laptop supports DDR4-SDRAM upgrades to achieve maximum memory specifications of 32 GB across both memory slots.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 1600 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-1600 (PC4-12800) |
| Bandwidth | 12.8 GB/s |
| Laptop Release date | 10 February 2018 |
Additional Notes
- The 2 SO-DIMM slot configuration permits dual-channel memory architecture, enabling theoretical bandwidth of approximately 25.6 GB/s at the specified 1600 MHz frequency; single-slot population forces single-channel operation with halved bandwidth capacity.
- Upgrading beyond the factory configuration to the 32 GB maximum requires both slots populated with 16 GB SO-DIMM modules; mixed capacity configurations (e.g., 8 GB + 16 GB) result in the 8 GB module operating at reduced speeds relative to the larger module, creating asymmetric performance degradation.
- The 1600 MHz frequency indicates DDR4-1600 specification; memory modules rated for higher frequencies (DDR4-2400, DDR4-3200) will downclock to 1600 MHz when installed, rendering premium modules functionally equivalent to base-frequency alternatives without performance gain.
- SO-DIMM form factor physical dimensions constrain upgrade options; desktop DDR4 UDIMM modules cannot be mechanically installed, and SO-DIMM sourcing remains limited compared to standard laptop modules, potentially extending procurement timelines.
- Laptop thermal design places SO-DIMM modules in close proximity to other components; high-capacity 16 GB SO-DIMM units with integrated heat spreaders may contact internal chassis elements or cooling systems, requiring clearance verification before installation.
- JEDEC compliance at 1600 MHz suggests compatibility with any DDR4-1600 or higher-rated SO-DIMM module; however, non-ECC consumer-grade modules are standard for this platform, and ECC variants may trigger BIOS rejection or stability issues.
