ASUS ROG GX650RX-LO180X RAM upgrade specifications
ASUS ROG Zephyrus Duo 16 GX650RX-LO180X compatible RAM specifications include DDR5-SDRAM memory with maximum upgrade capacity of 64 GB across 2x SO-DIMM slots. Memory operates at 4800 MHz frequency. Upgrade specifications support SO-DIMM form factor modules compatible with DDR5 standard specifications for enhanced laptop performance and multitasking capability.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 25 October 2022 |
Additional Notes
- Full capacity utilization requires the replacement of all pre-installed modules because the dual slot architecture lacks additional vacant headers for expansion.
- The ASUS ROG GX650RX-LO180X hardware architecture necessitates symmetrical pairing of modules to enable dual channel memory bandwidth for optimal processor throughput.
- Installing modules with higher frequency ratings will result in automatic downclocking to the system bus limit of 4800 MHz due to firmware clock speed governance.
- The use of SO-DIMM modules implies a tool-based physical installation requirement involving the removal of the lower chassis panel and potential contact with delicate internal ribbon cables.
- Latency performance depends on the integrated memory controller within the CPU, meaning that 64 GB configurations may see slight variations in timing compared to lower density setups.
- The absence of soldered memory on the motherboard ensures that the entire system memory remains serviceable and replaceable in the event of a single module failure.
