ASUS TUF Dash F15-TUF517ZM-HN001W RAM upgrade specifications
ASUS TUF Dash F15-TUF517ZM-HN001W laptop features DDR5-SDRAM memory upgrade capacity with two SO-DIMM slots supporting maximum RAM of 32 GB. Compatible memory operates at 4800 MHz frequency. Specifications indicate upgrade potential through dual SO-DIMM slots, enabling users to expand memory configuration up to the stated maximum capacity. Memory type DDR5-SDRAM provides enhanced performance specifications compared to previous generations.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
Additional Notes
- The ASUS TUF Dash F15 contains 2 SO-DIMM slots operating at 4800 MHz, which means memory upgrades are limited to a theoretical maximum of 32 GB total capacity. Expansion beyond this ceiling requires a complete memory module replacement rather than additive upgrades.
- DDR5-4800 memory operates at significantly higher bandwidth than DDR4 equivalents, but this performance gain depends on CPU-to-memory latency characteristics. Mismatched module speeds or timings can force the system to downclock to lower frequencies, negating the native 4800 MHz advantage.
- SO-DIMM physical constraints impose thermal restrictions in laptop form factors. Heat dissipation from high-speed DDR5 modules occurs in close proximity to the chassis floor, CPU socket, and other components. Replacement modules without integrated heat spreaders may cause localized temperature rises that trigger memory throttling or BIOS warnings.
- Single-slot memory population on one of the 2 SO-DIMM positions will disable dual-channel operation, reducing effective bandwidth by approximately 50 percent and increasing memory access latency. This configuration mismatch negates the speed benefits of 4800 MHz operation.
- BIOS firmware versions shipped with this model may not recognize DDR5 modules manufactured after the original release date. Capacity detection errors or stability issues can occur until BIOS updates are applied, and not all OEM updates guarantee SO-DIMM compatibility across all vendors.
- Warranty coverage for RAM upgrades typically remains intact only when using modules from ASUS's approved compatibility list. Third-party DDR5-4800 SO-DIMM installation may void memory-related warranty claims even if hardware damage is absent.
