ASUS TUF Dash FX516PE-HN020T RAM upgrade specifications
ASUS TUF Dash F15 FX516PE-HN020T memory upgrade specifications include DDR4-SDRAM support with one SO-DIMM slot for RAM expansion. Maximum compatible memory capacity reaches 32 GB, with operational frequency of 3200 MHz. The laptop features on-board memory combined with SO-DIMM slot configuration. Upgrade RAM compatible with DDR4-SDRAM specifications to enhance system performance and multitasking capabilities. Memory slots support single SO-DIMM installation for maximum capacity expansion.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 26 May 2021 |
Additional Notes
- The ASUS TUF Dash FX516PE-HN020T contains soldered on-board memory paired with a single upgradeable SO-DIMM slot, creating an asymmetrical configuration that limits scaling capacity compared to dual-slot designs.
- Adding a 32 GB SO-DIMM module would result in mixed-rank memory operation, as the soldered portion cannot be removed, potentially reducing effective bandwidth through asymmetric dual-channel access patterns.
- DDR4-3200 MHz compatibility requires validation against the on-board chip's specifications, as SO-DIMM replacements operating at identical frequency may still experience timing negotiation issues if the soldered memory operates at lower timings or voltage specifications.
- The single SO-DIMM slot creates a single point of failure for user-upgradeable capacity; any malfunction in this slot eliminates all expansion capability without motherboard-level repair.
- Upgrade headroom terminates at 32 GB total system memory, establishing a hard performance ceiling for memory-intensive workflows such as virtual machine hosting, large dataset processing, or concurrent application environments.
- SO-DIMM modules require physical removal of keyboard or base panels for installation, extending maintenance time and increasing mechanical stress on connector contacts compared to desktop-class DIMM slots with lever-release mechanisms.
- Warranty compliance for RAM upgrades on this model may restrict third-party module installation to manufacturer-qualified components; verifying ASUS compatibility documentation prior to purchase prevents warranty claim denial.
