ASUS TUF Dash TUF516PM-HN025T RAM upgrade specifications

ASUS TUF Dash F15 series model TUF516PM-HN025T supports DDR4-SDRAM memory upgrades. The laptop features one SO-DIMM slot for RAM expansion, with maximum memory capacity of 32 GB. Compatible memory modules operate at 3200 MHz frequency. The system utilizes a hybrid configuration combining on-board memory with the expandable SO-DIMM slot. Specifications indicate upgrade compatibility with DDR4 technology, enabling users to expand total RAM capacity up to the maximum supported specifications.

Additional Notes

• The presence of a single SO-DIMM slot combined with soldered memory creates an asynchronous memory architecture if the capacities do not match.
• Dual-channel bandwidth is restricted to the capacity of the smallest module, forcing any remaining memory into single-channel mode which reduces data throughput for integrated tasks.
• System stability depends on matching the 3200 MHz JEDEC profile of the on-board chips as the BIOS lacks XMP support for manual voltage or timing adjustments.
• Total memory expansion is capped by the motherboard firmware despite the physical ability of 32 GB modules to fit into the slot.
• The ASUS TUF Dash TUF516PM-HN025T requires low-voltage 1.2V modules to ensure thermal efficiency and compatibility with the existing soldered power delivery system.
• Upgrading the removable module involves removing the entire bottom chassis cover which may require specific tools to avoid damaging the plastic clips or interfering with the internal battery connection.
• Latency parity between the soldered memory and the expansion card is necessary to prevent the system from downclocking to the lowest common frequency.
