ASUS TUF Dash TUF516PM-HN125T RAM upgrade specifications
ASUS TUF Dash F15 model TUF516PM-HN125T features DDR4-SDRAM memory upgrade specifications. The laptop contains one SO-DIMM slot available for RAM expansion. Maximum memory capacity reaches 32 GB through the upgradeable slot. Compatible memory operates at 3200 MHz frequency. The system combines on-board memory with one replaceable SO-DIMM slot. Specifications support DDR4 memory modules for upgrade compatibility.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 10 September 2021 |
Additional Notes
- The ASUS TUF Dash 15 contains soldered on-board memory alongside a single SO-DIMM slot, restricting total expandable capacity to 16 GB despite a 32 GB system maximum. The soldered portion cannot be replaced or upgraded.
- DDR4-3200 MHz modules are mature, widely available components with stable pricing, but supply may be constrained relative to newer DDR5 alternatives. Procurement timelines remain predictable for this generation.
- SO-DIMM form factor compatibility is manufacturer-specific regarding voltage tolerance and timing profiles. Modules rated for 1.2V nominal operation align with mobile DDR4 specifications, but compatibility validation against ASUS OEM qualification lists is necessary before installation.
- Single-slot architecture eliminates dual-channel memory configuration options. Performance bandwidth remains limited to single-channel throughput regardless of installed module capacity, affecting sustained data transfer rates in memory-intensive workloads.
- Thermal constraints in laptop chassis design may prevent sustained operation at rated frequencies under heavy memory load combined with GPU utilization. Voltage regulation modules on the motherboard experience elevated thermal dissipation with maximum-capacity upgrades.
- Warranty preservation requires installation by authorized service centers for most ASUS TUF models. Self-installation voids coverage on memory-related hardware failures in many regional markets, though data integrity claims may remain covered.
