ASUS TUF Gaming FA506IU-HN304 RAM upgrade specifications
ASUS TUF Gaming A15 FA506IU-HN304 laptop supports DDR4-SDRAM memory upgrades with 2x SO-DIMM slots. Maximum RAM capacity reaches 32 GB total. Compatible memory operates at 3200 MHz frequency using SO-DIMM form factor. Memory upgrade specifications enable expansion from factory configuration to full 32 GB capacity for enhanced multitasking and performance capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 13 January 2021 |
Additional Notes
- Dual channel memory architecture requires installing matching pairs of modules to maximize the available memory bandwidth for the Ryzen processor.
- The absence of soldered memory on the ASUS TUF Gaming FA506IU-HN304 motherboard enables the replacement of both factory modules to reach the maximum threshold.
- Installing modules with speeds exceeding 3200 MHz results in automatic downclocking to the system bus limit determined by the chipset.
- High density 16 GB modules are required for each slot to achieve the 32 GB peak capacity because the firmware does not support 32 GB individual sticks.
- Upgrading memory necessitates use of standard 1.2V DDR4 modules as high voltage XMP profiles are typically not supported in this BIOS environment.
- Physical access to both SO-DIMM slots requires the removal of the entire bottom chassis panel which exposes internal components to electrostatic discharge risks.
- Populating both slots reduces latency in CPU bound gaming scenarios compared to single stick configurations.
