ASUS TUF Gaming FA506NC-HN003W RAM upgrade specifications
ASUS TUF Gaming A15 FA506NC-HN003W features DDR5-SDRAM memory upgrade capacity. The laptop contains 2x SO-DIMM slots supporting maximum RAM expansion to 32 GB total. Compatible memory specifications include DDR5-SDRAM operating at 5600 MHz frequency. Upgrade slots accommodate standard SO-DIMM form factor modules. Specifications allow dual-channel memory configuration for enhanced performance capacity on gaming and productivity workloads.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 5600 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-5600 (PC5-44800) |
| Bandwidth | 44.8 GB/s |
Additional Notes
- Dual channel architecture requires matching module pairs to achieve full memory bandwidth and reduce latency during high load gaming scenarios.
- The 32 GB threshold represents the maximum capacity addressable by the BIOS firmware, preventing the use of higher density 24 GB or 32 GB individual modules.
- The ASUS TUF Gaming FA506NC-HN003W requires high speed JEDEC profiles as XMP or DOCP overclocking settings are typically locked in the system firmware.
- Lower frequency modules will force the memory controller to downclock, resulting in a performance ceiling below the rated peak of the hardware.
- Installation of new memory necessitates a full power cycle and CMOS handshake before the first boot to train the new timing parameters.
- Physical access to the dual SO-DIMM slots involves removing the entire bottom chassis cover, which may involve varying screw lengths and plastic retention clips.
- Integrated graphics performance scales directly with memory speed, meaning throughput will drop if non-parity modules are used in a single channel configuration.
