ASUS TUF Gaming FA507NU-LP053 RAM upgrade specifications
ASUS TUF Gaming A15 FA507NU-LP053 laptop features DDR5-SDRAM memory upgrade capabilities. The system includes 2 SO-DIMM slots supporting maximum RAM capacity of 32 GB total. Memory specifications indicate DDR5 operation at 4800 MHz frequency. Compatible upgrades utilize SO-DIMM form factor modules. Maximum expandable memory configuration reaches 32 GB across both slots, enabling significant performance enhancements for multitasking and resource-intensive applications on the FA507NU-LP053 model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 10 April 2023 |
Additional Notes
- The presence of 2 physical SO-DIMM slots confirms that the system maintains a fully modular memory architecture rather than utilizing non-replaceable soldered chips.
- Utilizing both available slots enables dual-channel memory mode which significantly increases bandwidth for integrated graphics workloads and CPU-bound gaming scenarios.
- The 4800 MHz DDR5 standard operates at a lower voltage than previous generation DDR4 memory resulting in improved thermal efficiency during high-load processing tasks.
- Maxing out the ASUS TUF Gaming FA507NU-LP053 at 32 GB of RAM requires the replacement of any existing modules because no additional unoccupied slots exist beyond the primary 2.
- Installing memory modules with speeds exceeding 4800 MHz will result in the system down-clocking the hardware to the maximum frequency supported by the motherboard firmware.
- Matching the capacity and latency of the sticks in both slots is necessary to avoid stability issues or the system defaulting to single-channel performance speeds.
- Physical access to the memory slots involves removing the base panel which exposes internal components to potential electrostatic discharge risks during the installation process.
