ASUS TUF Gaming FA507NU-LP101 RAM upgrade specifications
ASUS TUF Gaming A15 FA507NU-LP101 laptop features DDR5-SDRAM memory upgrade specifications with two SO-DIMM slots supporting maximum RAM capacity of 32 GB. Compatible memory modules operate at 4800 MHz frequency. Specifications indicate SO-DIMM form factor for memory expansion. Current upgrade options allow installation of additional RAM modules in available slots to enhance system performance and multitasking capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
Additional Notes
- Dual slot architecture facilitates symmetrical dual channel memory configurations to maximize CPU memory controller throughput.
- The 32 GB motherboard ceiling limits the device to 16 GB modules per slot, preventing the use of high density 32 GB or 48 GB SO-DIMM sticks.
- Utilizing DDR5 at 4800 MHz requires modules with matching integrated Power Management Integrated Circuits to ensure voltage stability during high load gaming sessions.
- The ASUS TUF Gaming FA507NU-LP101 physical layout necessitates standard height SO-DIMM modules to prevent interference with the internal heat pipe assembly or bottom chassis cover.
- Upgrading from a single module to a dual module configuration significantly reduces 1 percent low frame rate drops in modern titles by doubling available bandwidth.
- Latency performance depends on the On-Die Error Correction Code inherent to the DDR5 standard, which functions independently of the CPU for improved data integrity.
- System stability is contingent on using non-ECC unbuffered memory as the motherboard firmware lacks support for registered or buffered server grade modules.
