ASUS TUF Gaming FA507NU-LP101W RAM upgrade specifications
The ASUS TUF Gaming A15 FA507NU-LP101W supports DDR5-SDRAM memory upgrades via two SO-DIMM slots. Compatible RAM modules operate at 4800 MHz frequency with a maximum total capacity of 32 GB. The laptop specifications accommodate SO-DIMM form factor memory upgrades for enhanced performance. Current memory configuration and available slots determine upgrade capacity and specifications for this gaming model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
Additional Notes
- The ASUS TUF Gaming FA507NU-LP101W contains 2 SO-DIMM slots with a combined ceiling of 32 GB, indicating each slot supports a maximum module capacity of 16 GB per stick.
- DDR5-4800 MHz operation requires memory modules rated for JEDEC DDR5-4800 or higher specifications; modules rated for lower frequencies will clock down to the laptop's native speed, resulting in no performance gain from faster memory purchases.
- SO-DIMM form factor occupies 67.6 mm length and 30 mm width, making physical access challenging in compact chassis designs; thermal management around SO-DIMM slots may restrict heatspreader height to approximately 7-10 mm on aftermarket modules.
- Dual-channel configuration becomes achievable only when both slots contain identical capacity and frequency modules; mismatched pairs will operate in single-channel mode on the smaller capacity, creating bandwidth bottlenecks and negating up to 50 percent of memory throughput potential.
- Upgrading beyond the factory configuration to 32 GB total requires removing the original modules and replacing both sticks simultaneously, as the laptop does not support asymmetrical populations within the 2-slot architecture.
- DDR5 memory operates at 1.1 volts nominal, while DDR4 operates at 1.2 volts; attempting DDR4 module installation will either prevent POST or cause immediate system shutdown due to incompatible electrical signaling and keying notch misalignment.
- Warranty considerations vary by region and retailer, but most laptop manufacturers permit RAM upgrades without voiding coverage when performed by end users using compatible modules; however, improper installation causing physical damage to slot contacts remains user liable.
