ASUS TUF Gaming FA507RE-HN061W-BE RAM upgrade specifications
The ASUS TUF Gaming A15 FA507RE-HN061W-BE laptop features two SO-DIMM memory slots supporting DDR5-SDRAM upgrade capacity. The system accommodates a maximum RAM configuration of 32 GB, with compatible memory modules operating at 4800 MHz frequency. Specifications allow for modular memory upgrades utilizing the SO-DIMM form factor, enabling users to expand existing RAM capacity within the stated maximum limitations of the device.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 10 January 2022 |
Additional Notes
- The dual channel configuration requirement necessitates installing modules in pairs to achieve the maximum theoretical memory bandwidth for the processor.
- The ASUS TUF Gaming FA507RE-HN061W-BE utilizes a motherboard architecture that limits expansion to 16 GB per slot due to firmware addressable space constraints.
- Memory modules exceeding the specified 4800 MHz frequency will automatically downclock to match the hardware controller limit of the system.
- Upgrading memory requires the removal of the bottom chassis panel which may involve breaking factory tamper seals depending on regional warranty policies.
- The transition to DDR5 technology improves power efficiency through on-module voltage regulation instead of relying on the motherboard power management integrated circuit.
- Installation of non-matching latency timings between the 2 slots will force the system to operate at the slowest common denominator potentially increasing system latency.
- Physical height clearances within the SODIMM slots prevent the use of memory modules equipped with thick aftermarket heat spreaders.
