ASUS TUF Gaming FA607PI-N3018W RAM upgrade specifications
ASUS TUF Gaming A16 FA607PI-N3018W features DDR5-SDRAM memory upgrade capability with two SO-DIMM slots supporting maximum capacity of 32 GB RAM. Compatible memory operates at 5200 MHz frequency. Specifications enable dual-channel memory configuration for enhanced performance. Upgrade options accommodate SO-DIMM form factor modules, with each slot accepting up to 16 GB capacity for full compatibility with specified maximum RAM parameters.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 5200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-5200 (PC5-41600) |
| Bandwidth | 41.6 GB/s |
Additional Notes
- The ASUS TUF Gaming FA607PI-N3018W supports DDR5 memory at 5200 MHz native frequency, which means aftermarket DDR5 modules rated at higher speeds (5600 MHz, 6000 MHz, or above) will operate at reduced 5200 MHz timings unless BIOS profiles enable XMP/DOCP overclocking.
- SO-DIMM form factor restricts upgrade sources to laptop-specific memory modules; desktop DDR5 UDIMM sticks cannot be installed regardless of speed or capacity compatibility.
- With 2 slots available and 32 GB maximum capacity, the configuration allows only 2 upgrade paths: single 32 GB module for 32 GB total, or 2x16 GB for the same maximum. Single-slot population will operate in single-channel mode, reducing memory bandwidth by approximately 50 percent compared to dual-channel operation.
- The 2-slot constraint means users cannot retain existing factory memory while adding a single additional module; any upgrade requires either replacement of both modules or acceptance of asymmetrical dual-channel operation if mixing capacities (for example, original module plus one new module).
- DDR5-5200 specification indicates the motherboard lacks native support for JEDEC DDR5-6400 standard, creating compatibility uncertainty with future module stock marketed primarily at higher JEDEC speeds; older DDR5-4800 modules will function but operate above their rated specification.
- SO-DIMM installation typically does not void manufacturer warranty when performed by end users, but memory modules themselves carry separate vendor warranties independent of the laptop chassis warranty.
