ASUS TUF Gaming FA707NU-HX038W RAM upgrade specifications
The ASUS TUF Gaming A17 FA707NU-HX038W features DDR5-SDRAM memory specifications with two SO-DIMM slots for RAM upgrades. Maximum compatible memory capacity reaches 32 GB total. The laptop supports DDR5 memory modules operating at 4800 MHz frequency. Upgrade options include individual SO-DIMM modules compatible with the two available slots, allowing users to expand memory capacity beyond factory configuration. Memory specifications provide the technical parameters required for compatible RAM upgrade selections for this TUF Gaming A17 model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 30 May 2023 |
Additional Notes
- The presence of 2 physical SO-DIMM slots allows for dual-channel memory configurations which significantly improves CPU inter-core communication and integrated graphics performance compared to single-channel setups.
- The maximum capacity limit of 32 GB suggests the motherboard firmware or processor architecture cannot address high-density 32 GB modules in each slot for a total of 64 GB.
- Installing memory modules with speeds exceeding 4800 MHz will result in the system down-clocking the ram to match the maximum supported BUS frequency of the ASUS TUF Gaming FA707NU-HX038W motherboard.
- DDR5 architecture utilizes on-die Error Correction Code which provides enhanced system stability during high-load gaming or rendering tasks without requiring specialized workstation buffered memory.
- Physical memory replacement requires the removal of the bottom chassis panel and the disconnection of the internal battery to prevent short circuits during the installation process.
- The laptop utilizes a non-soldered memory design which facilitates future maintenance and allows for the replacement of a single faulty module without needing a full motherboard swap.
- Total system latency is dictated by the CL timing of the installed modules where mismatched latency values between the 2 slots will force the system to operate at the slower module timing.
