ASUS TUF Gaming FX706IU-H7081T-BE RAM upgrade specifications
The ASUS TUF Gaming A17 FX706IU-H7081T-BE laptop supports DDR4-SDRAM memory upgrades with maximum capacity of 32 GB. The system features 2x SO-DIMM memory slots for expansion. Compatible memory modules operate at 3200 MHz frequency. Upgrade specifications indicate support for SO-DIMM form factor components. Maximum RAM configuration accommodates 16 GB per slot for total 32 GB capacity across both available memory slots.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 18 March 2020 |
Additional Notes
- Dual channel architecture requires matching memory modules across both slots to achieve maximum theoretical memory bandwidth.
- The 32 GB ceiling indicates a hardware limitation in the memory controller or BIOS that prevents the use of high density 32 GB single sticks.
- Upgrading the ASUS TUF Gaming FX706IU-H7081T-BE beyond the factory configuration necessitates the removal of existing modules since no vacant expansion slots remain available.
- System performance relies on modules with JEDEC profiles for 3200 MHz to avoid downclocking issues in environments without XMP BIOS support.
- Physical access to the SO-DIMM slots requires the removal of the entire base plate which involves navigating plastic clips and various screw lengths.
- Mixing modules with different CAS latencies forces the system to operate at the timings of the slowest installed component.
- The use of DDR4-SDRAM technology ensures lower power consumption and heat generation compared to older 1.5V memory standards.
