ASUS TUF Gaming TUF707NV-HX097W RAM upgrade specifications
ASUS TUF Gaming A17 series model TUF707NV-HX097W supports DDR5-SDRAM memory upgrades. The laptop features 2x SO-DIMM slots with maximum capacity of 32 GB total RAM. Compatible upgrades operate at 4800 MHz frequency using SO-DIMM form factor modules. Memory upgrade specifications enable users to expand system RAM to support enhanced multitasking and performance demands.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
Additional Notes
- The ASUS TUF Gaming TUF707NV-HX097W contains 2 SO-DIMM slots, which means both memory positions must be populated to achieve maximum capacity. Removal of either module reduces total addressable memory, regardless of remaining module size.
- DDR5-4800 MHz operation requires BIOS support for JEDEC compliance at that frequency tier. Systems shipping with earlier firmware may default to DDR5-4400 MHz or lower until a BIOS update is applied. Frequency downclocking does not affect stability but reduces memory bandwidth by approximately 100 MB/s per 400 MHz reduction.
- SO-DIMM memory modules occupy limited physical space within the laptop chassis. Heatspreaders taller than 12 mm may contact internal components or cooling solutions, particularly if thermal management components are positioned above the memory bay. Standard SO-DIMM profile heights (9-11 mm) pose no clearance risk.
- The 32 GB maximum capacity ceiling represents a hard platform limit. Exceeding this threshold through module substitution will not be recognized by the firmware and causes no operational degradation, but the excess capacity remains inaccessible. Single modules exceeding 16 GB per slot are therefore unsupported.
- DDR5 memory replacement constitutes a user-serviceable component upgrade path on this model. Warranty coverage typically remains intact provided no physical damage to retention clips, module contacts, or surrounding circuitry occurs during installation.
- Dual-channel memory configuration is achieved only when both SO-DIMM slots contain modules of equal capacity and matching specifications. Mismatched configurations (e.g., 16 GB + 8 GB) trigger single-channel operation on the smaller module, reducing effective bandwidth by up to 50 percent for memory-intensive workloads.
