ASUS TUF Gaming FX506HF-HN032W RAM upgrade specifications

ASUS FX506HF-HN032W ASUS FX506HF-HN032W ASUS FX506HF-HN032W ASUS FX506HF-HN032W ASUS FX506HF-HN032W

ASUS TUF Gaming F15 FX506HF-HN032W RAM upgrade specifications include DDR4-SDRAM memory compatible with 2x SO-DIMM slots. The upgrade supports a maximum capacity of 32 GB total memory at 3200 MHz frequency. Each slot accommodates SO-DIMM form factor memory modules. The specifications define compatible memory configurations for expanding system RAM on the FX506HF-HN032W model.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency3200 MHz
Maximum RAM32 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-3200 (PC4-25600)
Bandwidth25.6 GB/s
Laptop Release date30 March 2023

Additional Notes

  • Dual channel memory architecture is only achievable when both slots are occupied by matching modules to double the theoretical memory bandwidth.
  • The 32 GB limit restricts the 2 available slots to a maximum capacity of 16 GB per module.
  • Installing modules with speeds exceeding 3200 MHz will result in the hardware automatically downclocking the memory to match the processor bus limitations.
  • The ASUS FX506HF-HN032W relies on SO DIMM modules which require a specific physical clearance during installation compared to desktop style memory hardware.
  • System stability depends on using non ECC unbuffered modules to ensure compatibility with the standard gaming motherboard chipset.
  • Internal access for memory replacement involves removing the bottom chassis panel which may expose sensitive internal components to static discharge.
  • Mixing modules of different latencies will force the system to operate at the timings of the slowest installed component.
