ASUS TUF Gaming FX506LI-HN012 RAM upgrade specifications
ASUS TUF Gaming F15 series FX506LI-HN012 laptop features two SO-DIMM memory slots supporting DDR4-SDRAM upgrade capacity. Compatible memory modules operate at 2933 MHz frequency with maximum RAM specifications of 32 GB total capacity. RAM upgrade slots accommodate standard SO-DIMM form factor memory modules for system memory expansion and performance enhancement.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2933 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2933 (PC4-23464) |
| Bandwidth | 23.5 GB/s |
| Laptop Release date | 22 April 2021 |
Additional Notes
- The dual channel architecture requires identical module pairs to optimize memory bandwidth and reduce system latency during heavy processing tasks.
- The ASUS TUF Gaming FX506LI-HN012 motherboard lacks soldered memory which ensures that both modules remain replaceable if a hardware failure occurs.
- Installing 3200 MHz modules will result in automatic downclocking to the 2933 MHz platform limit due to chipset bus constraints.
- The 32 GB ceiling restricts high end virtualization or massive dataset processing but remains sufficient for current generation gaming requirements.
- Standard 1.2V DDR4 modules are required to maintain stability as higher voltage overclocking profiles are not supported by the system firmware.
- Achieving the maximum capacity necessitates the removal of any existing factory modules because the hardware configuration provides only 2 physical slots.
- Accessing the SO-DIMM slots requires the removal of the bottom chassis panel which may involve navigating plastic clips and internal ribbon cables.
